RVV Electrical lnstallation Cable

Brand Name : Zion communication OR OEM

Model Number : Electrical lnstallation Cable(RVV)

Certification : CE, RoHS, VDE, UL, CUL, LPCB

Place of Origin : China

MOQ : 20 KM

Payment Terms : T/T, L/C

Supply Ability : 1000KM / Month

Delivery Time : 25 working days

Packaging Details : 100M, 200M, Roll, Carton

Conductor : flexible ultra-fine stranded copper wire

Insulation : flexible heat resistant PVC

Color : Two core:black,white

Filler : cotton or pp filler

Jacket : flexble heat reslatant PVC mlxture

Produet reference standard : GB/T5023; JB8734

Contact Now

Electrical lnstallation Cable(RVV)
▉ Application
This cable is used as control and connec↑ing cables for electrical equipment.It apply to machine tool and complete sets of equipment for fixed installation.
▉ Cable Construction
Conductors: flexible ultra-fine stranded copper wire
Insulation:flexible heat resistant PVC
Insulation Color: Two core:black,white
Three core:blue,brown,yellow/green
Four:black,blue,brown,yellow/green
Five core and above:black insulated wire print white font
Filler:cotton or pp filler
Jacket:flexble heat reslatant PVC mlxture
Produet reference standard:GB/T5023; JB8734
Note:Cable having more than 3 core contain yellow/green wire
▉ Product Feature
Good mechanical properties
Good capabillity of electric insulation and resistant to chemicals
Fire resistance meets IEC60332-1
▉ Cross Section
RVV Electrical lnstallation Cable
▉ Technical data
Temperature Range Bend: : -5℃~＋70℃
Static : -15℃~＋70℃
Rated Voltage CCC : 300/300V 300/500V
IEC/VDE ＜ 1.5mm² ;300/300V
IEC/VDE ≥ 1.5mm² ;300/500V
Test Voltage ≥0.5mm² 2500V/5min;
Insulation resistance 20℃ ≥ 10MΩ/km
Min bending radius
Fixed 6D(D=cable diameter)
Moving 15D(D=cable diameter)
Torsion angle ±90°/m
Moving: ±90°/m
▉ Product List
Item No. Spec. Nominal OD(mm) Copper.weight approx (kg/km) Wight approx(kg/km)
7144100 RVV 2×0.5mm² 5.3 9 35
7144101 RVV 3×0.5mm² 5.6 14 45
7144102 RVV 4×0.5mm² 6.4 19 58
7144103 RVV 5×0.5mm² 6.9 23 68
7144104 RVV 10×0.5mm² 9.4 47 119
7144105 RVV 15×0.5mm² 11.4 70 188
7144106 RVV 20×0.5mm² 12.6 93 237
7144107 RVV 30×0.5mm² 14.7 140 331
7144108 RVV 2×0.75mm² 6.1 14 46
7144109 RVV 3×0.75mm² 6.5 21 61
7144110 RVV 4×0.75mm² 7.4 28 79
7144111 RVV 5×0.75mm² 8.0 35 93
7144112 RVV 10×0.75mm² 11.7 70 189
7144113 RVV 15×0.75mm² 13.3 105 260
7144114 RVV 20×0.75mm² 14.7 140 331
7144115 RVV 30×0.75mm² 17.2 209 467
7144116 RVV 2×1.0mm² 6.8 19 59
7144117 RVV 3×1.0mm² 7.2 28 78
7144118 RVV 4×1.0mm² 7.9 37 93
7144119 RVV 5×1.0mm² 8.6 47 111
7144120 RVV 10×1.0mm² 12.5 93 225
7144121 RVV 15×1.0mm² 14.3 140 311
7144122 RVV 20×1.0mm² 15.8 186 398
7144123 RVV 30×1.0mm² 20.7 279 664
▉ Product List
Item No. Spec. Nominal OD(mm) Copper.weight approx (kg/km) Wight approx(kg/km)
7144124 RVV 2×1.5mm² 7.8 27 77
7144125 RVV 3×1.5mm² 8.3 41 103
7144126 RVV 4×1.5mm² 9.1 55 126
7144127 RVV 5×1.5mm² 10.6 68 171
7144128 RVV 10×1.5mm² 14.5 136 306
7144129 RVV 15×1.5mm² 16.6 205 428
7144130 RVV 20×1.5mm² 20.6 273 649
7144131 RVV 30×1.5mm² 23.9 409 903
7144132 RVV 2×2.5mm² 9.0 45 107
7144133 RVV 3×2.5mm² 9.6 67 146
7144134 RVV 4×2.5mm² 11.2 89 202
7144135 RVV 5×2.5mm² 12.2 111 242
7144136 RVV 10×2.5mm² 16.9 223 442
7144137 RVV 15×2.5mm² 21.6 334 729
7144138 RVV 20×2.5mm² 23.8 445 926
7144139 RVV 30×2.5mm² 27.8 668 1306
▉ Order Informations
Marking HELLOSIGNAL Electrical lnstallation Cable(RVV) XXXFT/M
Package 100M/Reel, 300M/Wooden Spool
Delivery time Normally 25 days after received the deposit.
Brand HELLOSIGNAL® OR OEM
