Low loss 300 series cable Industry standard, Flexible, Low Loss Communications Coaxial cable

Brand Name : Zion communication OR OEM

Model Number : LLC Coax Cable

Certification : ISO, CE, RoHS, UL

Place of Origin : China

MOQ : 1 KM

Payment Terms : T/T, L/C

Supply Ability : 1000KM / Month

Delivery Time : 25 working days

Packaging Details : 100M, 300M, Wooden Reel, Carton

Inner Conductor : Bare Copper Wire

Dielectric : Foamed PE

Shield : Bonded Aluminum polyester tape

Outer Conductor : Tinned Copper Braid

Jacket : PE Black

More choice of Jacket : FRPE / PVC / PVC W

Contact Now

LLC 300 BC NO.7101005
Construction Parameters:
Inner Conductor 1.78±0.03mm Bare Copper Wire
Dielectric 4.83±0.15mm Foamed PE
Shield Bonded Aluminum polyester tape
Outer Conductor 5.72mm Tinned Copper Braid
Jacket 7.62±0.2mm PE Black
More choice of Jacket FRPE / PVC / PVC W
Electrical Characteristics:
Capacitance 78.8 pF/m
Low loss 300 series cable Industry standard, Flexible, Low Loss Communications Coaxial cable
Impedance 50±2 Ω
Velocity of Propagation 83%
Peak Power Rating 10 KW
Max.Operating Frequency 6 GHz
Insulation Resistantce >5000 M Ω.km
Shielding Effectiveness > 90 dB
Inner Conductor DC Resistance 7.0 Ω/km
Outer Conductor DC Resistance 7.3 Ω/km
VSWR ≤ (Return loss≥dB)
30MHz-3000MHz 1.20 (20)
Mechanical and Envrionmental Properties:
Cable Bend Radius Installation: 22.2mm
Repeated: 76.2mm
Compressive flat force
Maximum tension 54.5 kg
Bending Moment 0.52 N-m
Flat Plate Crush Stength 0.54 kg/mm
Recommended
Temperature		 Storage: - 70 ℃ to +85℃
Installation: - 40 ℃ to +85℃
Operating: - 40 ℃ to +85℃
Cross Section:

Low loss 300 series cable Industry standard, Flexible, Low Loss Communications Coaxial cable
Attenuation(20℃):
Frequency (MHZ) Max Attenuation(dB/100m) Avg.Power(KW)
30 3.50 2.09
50 4.50 1.62
150 7.90 0.92
220 9.60 0.76
450 13.80 0.52
900 19.90 0.36
1500 26.00 0.28
1800 28.70 0.25
2000 30.30 0.24
2500 34.20 0.21
3000 37.50 0.13
5800 54.30 0.11
Order Informations:
Marking HELLOSIGNAL LLC 300 50 Ohm COAXIAL CABLE ×××M
Package 500M/Wooden Drum, 1000M/Wooden Drum
Delivery time Normally 25 days after received the deposit.
Brand HELLOSIGNAL® OR OEM
Whatsapp/WeChat 0086 18268009191
Email info@zion-communication.com
